产品说明：

Introduction

该系列产品为典型的双锅筒纵置式"D"型布置快装水管锅炉。它由上下锅筒、膜式水冷壁、过热器、对流管束及省煤器组成，燃烧器布置在前墙，燃料在炉膛内燃烧后，烟气经过热器、对流管束及省煤器排入烟囱。该产品结构紧凑，占地面积小，火焰充满度好；采用下支承方式，能自有向上膨胀；炉膛水冷壁及对流烟道全部采用膜式壁结构，密封性好且有效降低耐火砖的使用及维修工作量；外包装采用彩钢板，外形美观、漂亮；采用全自动燃烧器，燃烧效率高并具有点火程序控制及超压、熄火保护功能；采用快装结构，能有效缩短安装周期。

The series boiler is typical double drums and package water-tube boiler with D arrangement It consists of steam and water drum,memberane wall,superheater,convective bank and economizer.Lay out the burner at the front wall.When fuel has been bumed inside of the furmace,the smoke goes through the superheater and economizer.And last goes to the chimney.The product is less occupying area with compact structure has good tightness and reduce the amount of fire bricks and maintenance load.The external packing uses colour steel plate with beautiful appearance.Fully-automatic combustor is used with high burning efficiency and ignition control program.It also has over pressure and flameout protective functions takes package structure to shorten installation period.

产品范围

Scope

蒸发量：35-37t/h，压力：3.82-5.3Mpa,蒸汽温度：450-540℃

Evaporation capacity:35-75t/h,pressure:3.83-5.3Mpa,steam temperature:450-540℃

注：由于本公司产品不断改进，以上产品参数将不断更新，本页所列仅供参考。表列锅炉品种为本厂代表产品，如需其他型号参数锅炉可参阅有关图纸资料
Parameters listed herein are just for reference as those are subject to continuous modification with prduct upgrading.
Listed models are typical.If other models are needed,please refer to drawings and data available.
